True GDM - G4 SM-23 RGS Shelf Bracket Assembly; Installing Shelves (GDM-30 only)

GLASS DOOR MERCHANDISERS truemfg.com
TEC_TM_105 REV. A03/19/2021 Page 12 of 22
Installing Shelves (GDM-30 only)
Tape door handles back to the cabinet when installing shelves
Shelf Bracket
O-Ring
Shelf Retaining Screw
Glass Shelf
O-Ring
Shelf Retaining Screw
G4SM-23RGS SHELF BRACKET ASSEMBLY
Cabinet Setup (cont.)
