GLASS DOOR MERCHANDISERS truemfg.com
TEC_TM_105 REV. A03/19/2021 Page 8 of 22
Installing optional castors on GDM-10 & 12 models
1. Position Styrofoam or cardboard on the floor behind the unit.
2. Carefully lay the unit on its back.
3. With a Phillips screwdriver, remove the front louver grill.
4. Remove the shipping bolts.
5. 5. Install the castors in the threaded holes.
NOTE: Be sure to position the castors with handbrakes at the
front of the cabinet.
6. Position the front castors forward and engage the brakes.
Warning - Unit may tip if the front castors are not positioned
forward and locked.
7. Install the front louver grill.
8. Carefully lift the unit.
NOTE: To avoid damage to the lower rail assembly, slowly
upright the unit.
9. Verify the unit is level. If needed, level the cabinet as directed
on page #.
Installation (cont.)
POSITIONING OF THE CASTOR
IS CRITICAL. ORIENT THE
CASTOR IN THE FORWARD
POSITION AS SHOWN.
