HOW TO TURN OFF THE LAE ELECTRONIC CONTROL:
May need to unlock control.
WHY: Turning off the control will deactivate all electrical components.
CAUTION: Turning off the control will not shut off power to the cabinet. Cabinet
must be unplugged prior to any repair.
HOW TO TURN OFF THE LAE ELECTRONIC CONTROL:
STEP 1 - To turn off control, press and hold the Stand-by button until
"OFF" appears. Release Stand-by button. See Image 2.
STEP 2 - To turn on control, repeat prior steps and a temperature will appear.
ON Position
TURNING THE GLASS DOOR MODEL LIGHTS ON AND OFF:
May need to unlock control.
WHY: Light may be controlled by LAE Controller or interior light switch.
(Solid Door model lights are controlled by a
door switch)
HOW TO TURN THE GLASS DOOR MODEL LIGHT ON
AND OFF:
STEP 1 - To control interior / sign lights by the LAE Controller, press and
release the Manual Activation button .
STEP 2 - To control interior / sign lights by the interior door switch, depress
the rocker switch to the “ON” position. Light switch is located on inside top
right of the ceiling.
1
2
LAE Control
Manual Activation
Up Button
Info / Set Point
Button
Stand-By
Button
Manual Defrost /
Down Button

True T-23F-HC Specifications

General

Number of Doors	1
Number of Shelves	3
Defrost System	Automatic
Color	Stainless Steel
Capacity	23 cubic feet
Refrigerant	R290
Voltage	115V
Total Capacity	23 cubic feet
Refrigerator Capacity	23 cu. ft.
Dimensions (H x W x D)	1370 x 595 x 625 mm
Weight	45 kg
