15
CHAPTER 2: ASSEMBLY INSTRUCTIONS
BIKE ASSEMBLY STEPS (continued):
a) Insert the Handlebar U-bracket onto the
Front Mast.
DO NOT PINCH CABLES.
b) For each screw, install through split washer
then flat
washer
c)
Secure the Handlebar to the Front Mast by
tightening all 3 screws with the provided hex
wrench
Hardware Required:
3 M8 x 70 Screws
3 M8 Washers
3 M8 Spring Washers
Step #6 Mast Boot:
a) Pull down the Mast Boot
b) Attach the Mast Boot to the plastic shrouds
by tightening both screws with a Phillips head
screwdriver (not provided).
Hardware Required:
2 M4 x 10 Scr
ews
a) While at least one person holds the
Handlebar, another person should direct the
Handlebar Cables through the Front Mast.
Step 8: Handlebar Assembly:
Step 7: Handlebar Cables
