VALUE
Environment
Temperature - operating
–10 to +50°C
Temperature - storage
–40 to +70°C
Altitude
2000 metres
Relative Humidity (non-condensing) - Continuous
0 – 85 %
Relative Humidity (non-condensing) - Intermittent
0 – 95 %
Overvoltage category (IEC664)
II
Pollution Degree (IEC664)
2
IP rating (from the front)
IP65
NEMA Rating (from the front)
Type 4 & Type 12
Vibration
Shock
Power supply
Input
100-277VAC
Max Power
2W
Supply Frequency
50-60Hz
Isolation
Reinforced
Display
Number of digits
4 x 3
Digit height
7.5 mm
Number of bar-graph segments
20 per phase
Number of starburst message characters
6
Backlight colours
Red, Green, White
LCD Positive or Negative
Digit update frequency
500ms
Bar-graph update frequency
500ms
Viewing angle
+/-70° Horizontal
+/-70° Vertical
Open Collector Sinking Outputs
Max voltage (open collector outputs)
24 VDC
Max current (open collector outputs)
15 mA
Analogue Output
Output
4-20 mA
Accuracy
0.50 %
Resolution 0.02 mA
Connections
Type
Screw Terminals
Wire type
Copper (Solid or
Stranded)
Min. cable temperature rating
65°C (149°F)
Wire strip length 6.5mm to 7mm
(0.26” to 0.28”)
Wire gauge
0.8mm² - 3.3mm²
(18AWG to 12AWG)
Torque
0.5-0.6Nm
(4.42-5.31 lbf-in)
In the Box
APM
Getting started & safety guide
Gasket
Retaining clip
Dimensions & Weight:
Panel Cut-out: 68 x 68 mm (2.68 in) +0.7 -0 mm (0.02 in). Max. panel thickness: 10
mm.
Dimensions: Depth behind panel inside front: 55mm (2.17in) incl. external
connections. Weight: 220 grams
Specification
