Trust ICS-2000 - 2. Connection Ports

ICS-2000 OCTOPUS CONTROL STATION
9
2. Connection ports
The control station has the following ports:
A
Micro USB Power port. Used for connecting the control station to a wall socket
B
Network port. Used for connecting to your home LAN network.
C
P1 port. Used for smart energy meters with a P1 connection. See trust.com/71110 for more info
D
USB ports. Used for future connectivity extensions. See trust.com/71110 for more info
P1
2
A
B
C
D
