5
ELECTRICAL CONNECTIO
ELECTRICAL CONNECTIOELECTRICAL CONNECTIO
ELECTRICAL CONNECTIONS
NSNS
NS
TER MINAL BO ARD DESC R
TER MINAL BO ARD DESC RTER MINAL BO ARD DESC R
TER MINAL BO ARD DESC R IPTION
IPT ION IPT ION
IPT ION
1
CH A Encoder input: A channel
2
CH B Not used
3
CH Z Not used
4
ABL Not used
5
+ Positive supply for encoder
6
- Negative supply for encoder
7
COM Outputs common
8
OUT 1 Output 1: first active threshold
9
OUT 2 Output 2: second active threshold
13
VAC Power suppply
Digital inputs
Opto-insulation 2500 V rms
Load current 10 mA
Impedance 1 kOhm
Polarization NPN
0 logic state voltage 0V + 6V
1 logic state voltage 10V + 12V
Digital outputs
Opto-insulation 2500 V rms
Commutable load
AC-DC
(NPN-PNP)
Maximum operating
tension
40 Vac/dc
Maximum current 500 mA
Connect only one conductor for each terminal and be sure that the power supply is as indicated on the back of the
device; use only cables properly insulated for operating tensions and temperature; keep power cables separated from
control cables.
Be very careful when connecting the device and follow the indications provided in the following diagram. Be sure that
the device is not connected to the power supply when carrying out all the electrical connections.
If the malfunction of this device may injures persons or damage things, it is stricly recommended to
install mechanical devices or protections to guarantee safety!
