TS line TS010 User Manual

8
Parameter
code
Function Range and allowed values Notes
Show device code; -
Show device code and firmware version
alternately;
Working parameters
modification;
0 Active;
1 Inactive;
Decimal point;
0 Inactive;
1-5 from 1 to 5 decimal digit;
Division ratio;
00.00÷999.999
Default = 1.00
Division ratio = (encoder frequency)/(desired value);
First treshold; From 000000 to 999999 ;
Second treshold From 000000 to 999999 ;
OUT 1 logic;
0 Positive logic;
1 Negative logic;
2 Positive pulse;
3 Negative pulse;
Timer OUT 1;
from 00,00 to 99,99 seconds;
if =0 or 1, the set value delays
OUT 1 activation;
if = 2 o 3, the set value is the
pulse duration;
OUT 2 logic;
0 Positive logic;
1 Negative logic;
2 Positive pulse;
3 Negative pulse;
Timer OUT 2; from 00,00 to 99,99 seconds;
if =0 or 1, the set value delays
OUT 1 activation;
if = 2 o 3, the set value is the
pulse duration;
Speed value acquisition
time;
from 0,1 to 9,9 seconds;
Set the maximum time between one
speed visualization and the other;
Bold and framed values are default ones;
