TScale AHC Series - Parts List

AHC/QHC series technical manual
- 24 -
PARTS LIST
NO
Parts Name
Qty
Material
Spec
1
Pan
1
SST
230mmX300mm
2
Pan
1
ABS
230mmX300mm
3
Battery Cover
1
ABS
4
Rear Overlay
1
5
Name Plate
1
6
Battery
1
Lead Acid
6V/4AH
7
Foam
1
CR
8
Load cell upper bracket
1
Aluminum
9
Load Cell
1
10
Hexagon Screw
4
20Mn
M4x16
11
Load cell lower bracket
1
Aluminum
12
Hexagon Nut
2
M3
13
DB9 Connector
1
Optional
14
Hexagon nut for D connector
2
Optional
15
“+” Self thread Screw
1
20 M
3x8
16
AC adaptor jack PCB
1
17
Front display overlay
1
PC
18
Key board
1
19
Level bubble
1
14.7mm
20
Top Cover
1
ABS
21
Internal hexagon screw
4
M6x16, 8.8
22
Spring Washer (M6)
4
HRC42-50
23
Washer (M6)
4
656Mn
200-300HV
24
Hexagon nut
4
M4
25
Self thread screw
4
20Mn
4x20
26
Main PCBA
1
27
Self thread screw
4
20Mn
3x12
28
Front Display PCBA
1
29
Insulative washer
5
EDPM
8x3.1x1.2t
30
Bottom Cover
1
ABS
31
Power Switch
1
32
Foot fixer
4
ABS
33
„+” Self thread screw
5
20Mn
M4x12
34
Foot
4
PVC
