TScale AHC Series - Dimension; Specifications

AHC/QHC series technical manual
- 25 -
10. DIMENSION
11. SPECIFICATIONS
MODEL
AHC/QHC
3000g
AHC/QHC
6000g
AHC/QHC
15kg
AHC/QHC
30kg
Capacity
3kg
6kg
15kg
30kg
Readability
0.05g
0.1g
0.2g
0.5
Tare Range
-3kg
-6kg
-10kg
-30kg
Minimum
1g
2g
4g
10g
Repeatability
0.05g
0.1g
0.2g
0.5g
Resolution
Up to 60000
Weighing Units
Kg
Housing
ABC Plastic and Stainless Steel platform
Interface
RS232 Output optional
Operation
Temperature
0°C - 40°C / 32°F - 104°F
Power
Power switch 12V/500mA , Battery 6V/4AH
Display
3x6 digits 20 mm LCD display wit white LED back light
Dimensions (WxDxH)
320 x 340 x 125mm / 12.6 x 13.4 x 4.9”
Weight
3.8kg/8.4lb
Internal Counts
600000
