AHC/QHC series technical manual
- 26 -
Load cell specifications
Model No
NA22
C2X1
Rated Capacity
6~40 (kg)
6~50 (kg)
Rated Out put
2.0mV/V± 0.2 mV/V
2.0 mV/V±0.2 mV/V
Excitation
Voltage
15 VDC
20 VDC
IP Level
IP65
IP64
Material
Aluminium Alloy
Aluminium Alloy
Cable
Φ 4x 35 cm
Φ 8.2 four core shield
Input Resistance
390Ω ±15Ω
420Ω ±30Ω
Out put
Resistance
350Ω ±5Ω
350 Ω ± 5 Ω
Temperature
Range
-20°C - 60°C
-10°C - 50°C
Safe overload
150 %RC
150 %R.C
Ultimate overload
200 %RC
200 %R.C
Repeatability
0.03 %R.O
0.02 %R.O
Creep
0.03 %R.O/ 3 min
0.02 %R.O/ 20min
Zero Balance
±0.02 mV/V
± 0.1 mV/V
