Manual of Mid-drive Conversion Motor——TSDZ8
Document No.：TSE-PM-MM-TSDZ8-A-01(EN)
Suzhou Tongsheng Electric Appliances Co., Ltd 3 / 11
≥
1 General Introduction
1.1 Safety
Read and understand all safety warnings and instructions. Failure to comply with the following
warnings may result in death or serious injury:
Do not attempt to change, especially increase, the power or maximum power of the motor, as well as
the speed it supports. Doing so may put yourself and others in danger, and you may also violate legal
regulations.
Do not open the motor body by yourself. The motor can only be repaired by professional
technicians using original spare parts to ensure the safety of the motor. Unauthorized opening of the
motor will render the warranty or claim invalid
1.2 Application
1.3 Scope of Application
1) TSDZ8 mid-drive conversion motor can convert your regular bike into an electric power assisted
bike——ebike. TSDZ8 is suitable for bikes with bottom bracket (BB) length of 68mm or 73mm.
2) The exposed length of TSDZ8 motor sleeve should be ≥ 10mm after insert into the BB of the bike.
Note: Before buying the motor, the measuring tool can determine if your bicycle size is available to
install the TSDZ8 motor. Please visit the following page(link) to find the "Download" button in the
"Conversion Kit" section and print it out with A4 paper. Then follow the steps in the document or the
video to make sure your bicycle is available to install the motor.
