3-8 Model 3786 Ultrafine Water-based Condensation Particle Counter
drain bottle must be connected back to the Vent connector on the
back panel.
Sample Inlet Connection
The Sample Inlet is located on the back of the UWCPC. Turn off the
pump before connecting or disconnecting sample sources. Keep
sample lines as short as possible. Use of metallic or conductive
sample lines is recommended to reduce particle losses due to
electrostatics. Avoid larger pressure restrictions (>25 cm water at
0.6 L/min) or sample sources with pulsating pressure.
