B-14 Model 3786 Ultrafine Water-based Condensation Particle Counter
SV Set Analog Output Voltage
This command sets the voltage on the analog output connector on the back panel of
the UWCPC. This command will return an ERROR if the UWCPC is operating in
scanning mode (SM,5 or SM,6 see SM command).
Command: SV,xxx Command to set analog output voltage
xxx = 0 to 10000 (mv)
Response: OK Response
Example: SV,2000 Command to set analog output voltage to 2.0 volts
OK Response
SV Command to read back the current setting
2000 Response
SVS Set Analog Voltage Span
This command sets the span value used for the analog output voltage.
Command: SVS,xxx Command to set analog voltage span value
xxx = 1 to 65535
Response: OK Response
Example: SVS,3276 Command to set analog voltage span to 3276
OK Response
SVS Command to read back the current setting
3276 Response
SVZ Set Analog Voltage Zero
This command sets the analog output zero levels.
Command: SVZ,hhh,lll Command to set high and low analog output zero level
hhh = 0 to 4095
lll = 0 to 4095
Response: OK Response
Example: SVZ,200,300 Command to set analog output zero values
OK Response
SVZ Command to read back the current settings
200,300 Response
SZ Set Auto
Zero Function
This command executes an auto zero function that calibrates the photo detector
offset, the dead-time measuring circuit, and the flow transducer zero value.
WARNING
This command will affect the instrument’s calibration.
