TSI Instruments AEROTRAK 7201-A2F User Manual

1–1
C H A P T E R 1
Introduction and
Unpacking
The AeroTrak
®
Remote Airborne Particle Counter (particle counter) is a
compact sensor that is appropriate for use in multiple locations in a large
clean room or critical environment to continuously monitor a process. The
sensors are very simple compared to a typical particle counter. They
have no display (other than several LED indicators) and no pump (central
vacuum is used along with an integral critical orifice).
Sensor data and particle counter information is communicated to an
external device via 4-20 mA outputs and a digital contact. Oftentimes, this
data is sent to a data logging software, like TSI’s Facility Monitoring
Software.
The following table shows the remote particle counter models covered by
this manual.
Model
Size
Range
(µm)
Flow Rate
No. Size
Channels*
Size Channels
(µm)
7201-A2F
0.2 to 10
2.8 L/min (0.1 cfm)
4
0.2/0.3/0.5/1 µm
7301-A2F
0.3 to 25
2.8 L/min (0.1 cfm)
4
0.3/0.5/1/5 µm
7310-A3F
0.3 to 25
28.3 L/min (1 cfm)
4
0.3/0.5/1/5 µm
7501-A2F
0.5 to 25
2.8 L/min (0.1 cfm)
4
0.5/1/2/5 µm
7510-A2F
0.5 to 25
28.3 L/min (1 cfm)
4
0.5/0.7/1/5 µm
*While these Remote Particle Counters have four size channels, only two analog outputs
are available to use at any one time.

TSI Instruments AEROTRAK 7201-A2F Specifications

General

Brand	TSI Instruments
Model	AEROTRAK 7201-A2F
Category	Cash Counter
Language	English
