Specifications A–7
Switch bank 2 (SW200) is for channel, characteristic and scale selection of
Channel "2"
Channel
Selection
Switch sw1 Position
Switch sw2 Position
Selected Channel
ON
ON
CH 1
ON
OFF
CH 2
OFF
ON
CH 3
OFF
OFF
CH 4
Characteristics
Selection
Switch sw3 Position
Characteristic
ON
Linear
OFF
Log
Scale Selection
for Linear Scale
Only
Switch sw4 Position
Switch sw5 Position
Switch sw6
Position
Range
ON
ON
ON
IE 2
100
ON
ON
OFF
IE 3
1000
ON
OFF
ON
IE 4
10000
ON
OFF
OFF
IE 5
100000
OFF
ON
ON
IE 6
1000000
OFF
ON
OFF
IE 7
10000000
OFF
OFF
ON
IE 8
100000000
OFF
OFF
OFF
IE 9
1000000000
Switch sw7 Position
Switch sw8 Position
Do not care
Do not care
