TSI Instruments PRESSURA RPC30

p. 3 of 20
Figure 3: Cutaway View of Mounted Pressure Sensor
Figure 4: Pressure Sensor Mounting
CEILING
DUMMY
COVER
CONTROLLED SPACE
REFERENCE SPACE
(TYPICALLY A HALLWAY)
BLACK FIRE SEALANT RING
MUST INSERT INTO
2 ¼” HOLE
PRESSURE
SENSOR
½ THE DISTANCE
BETWEEN CEILING
& DOOR JAMB
WALL
