–Iftheshuttermovesbeyondthepointatwhichlimitswitch“1”istobe
fixed,stopmovementandthenactivatetheshuttertomoveitbacktothestartingpo-
sition;thenturntheadjustmentscrewoflimitposition“1”throughafewturnsinthe
directionofthe“–”signandrepeattheprocedurefrompoint07.
08.Graduallyturntheadjustmentscrewoflimitposition“1”inthedirectionofthe“+”
sign,totherequiredstopposition“1”.Note – on each turn of the screw, the motor
movestostopinthenewposition.
