12
SP-403 Multi-Press
Owner’s Manual: Assembly Instructions
Item No. Description Part No. Qty Item No. Description Part No. Qty
1 WEIGHT STACK FRAME 54" UP0780 1 54 PLASTIC INSERT CAP 2" SQ. BNH0012 2
2 WEIGHT SHROUD 54" UP0781 1 55 RUBBER GRIP 1 ID X .125 X 4 1/2 BNH1129 2
3 WEIGHT SHROUD W/PLATE 54" UP0782 1 56 RUBBER GRIP 1 ID X .125 X 15 BNH1072 2
4 GUIDE ROD 3/4 X 53 5/8 UP0783 2 57 PLASTIC BLACK KNOB W/NYLON STUD 1/2-13 BNH0796 1
5 GUIDE ROD RETAINER UP0784 1 58 PYRAMID RUBBER BUMPER BNH0013 1
7 WEIGHT STACK SPACER 4" UP0786 2 59 UHMW STOPPER 27/64 ID X 1 1/2 OD X 1 BNH1314 1
8 15 LB WEIGHT PLATE BNH0926 19 60 RUBBER BUMPER 3/8 X 1 1/2 BNH0514 1
9 10 LB TOP PLATE W/ADJ. SLTR BAR 19 WTS BNH1100 1 62 SPLIT LOCK WASHER B/O 1/2" BNH0653 2
10 PLASTIC SHROUD GAP COVER 24" BNH1437 1 64 CHROME WASHER 3/8 X 1 1/2 BNH1015 2
11 PLASTIC SHROUD LID 5/8 X 14-1/8 X 10 BNH0185 1 65 SPLIT LOCK WASHER B/O 3/8" BNH0658 2
12 EDGE PROTECTOR GRAY 30" BNH0601 2 66 SPLIT LOCK WASHER Z/P 1/2" BNH0572 2
13 EDGE PROTECTOR GRAY 54" BNH1148 2 67 PUSH PULL PIN 1/2 X 5 5/8 BNH0586 2
14 URETHANE BUMPER 1 3/4 BNH0229 3 68 BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8 BNH0527 2
15 RUBBER DONUT 3/4 X 2 1/2 BNH0068 2 69 FINISHED HEX NUT B/O 1/2-13 BNH0201 1
16 NYLON PULLEY 4 1/2 RD. WHITE BNH0556 6 70 ALUMINUM CAP 1" RD. (CAP-100) BNH0537 4
17 U-STYLE TAPPED HOLE NUT 1/4-20 BNH0708 8 71 SOCKET SET SCREW ALLOY 10-32 X 1/8 BNH0473 8
18 FLAT WASHER USS B/O 3/4 X 2" BNH0878 4 72 BALL BEARING #W 516 BNH0628 2
19 FLAT WASHER SAE B/O 3/8" BNH0239 26 73 BRONZE BUSHING 1/2 X 5/8 X 1 BNH0112 6
20 FLAT WASHER SAE B/O #12 (1/4") BNH0877 8 74 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 BNH0275 1
21 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 3/4 BNH0890 8 75 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/4 BNH0273 6
22 NYLON INSERT LOCK NUT B/O 1/2-13 BNH0212 9 76 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/2 BNH0303 2
23 NYLON INSERT JAM LOCK NUT B/O 3/8-16 BNH0365 7 77 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 BNH0282 2
24 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 3 1/2 BNH0263 4 78 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 3 1/4 BNH0576 2
25 FLAT HEAD SOCKET CAP SCREW B/O 3/8-16 X 3 BNH0787 2 79 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 BNH0115 2
26 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 BNH0279 4 80 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 1 BNH0259 2
27 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 BNH0274 2 81 HEX HEAD CAP SCREW GR-5 B/O 1/2 13 X 1 1/2 BNH0727 1
28 RUBBER GROMMET 3/4" ID (2867-012) BNH0401 2 82 DECAL-NUMBERS 20-200 LBS. SET BNH1202 1
29 FLAT WASHER SAE B/O 1/2" BNH0238 26 83 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 4 1/2 BNH0265 2
30 NYLON INSERT LOCK NUT B/O 3/8-16 BNH0214 2 84 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 4 3/4 BNH0895 4
31 PRESS BAR UP0829 1 85 NYLON INSERT JAM LOCK NUT B/O 1/2-13 BNH0366 3
32 PRESS BAR MAIN FRAME UP0835 1 86 SOCKET SET SCREW ALLOY 1/4-20 X 1/4 BNH0790 2
33 PRESS BAR PIVOT ARM UP0823 1 87 MULTI-PRESS CABLE UP0925 1
34 PRESS BAR PIVOT AXLE UP0827 1 88 CABLE HEX TAP BOLT Z/P 1/2-13 X 3 BNH1048 1
35 PIVOT ARM AXLE UP0807 1 89 ROD END 1/2 X 20 BNH0674 1
36 BENCH BACK PAD FRAME UP0442 1 90 CABLE HEX BOLT GR-8 Z/Y 1/2-20 X 1 BNH1045 1
37 BENCH SUPPORT BAR UP0443 1 91 HEX KEY ALLOY 3/32" BNH0372 1
38 BOTTOM CROSS BRACE UP0830 1 92 HEX KEY ALLOY 1/8" BNH0797 1
39 REAR CROSS BRACE UP0831 1 93 HEX KEY ALLOY 7/32" BNH0575 1
40 BENCH MAIN FRAME UP4637 1 94 SELECTOR PIN W/COIL 3/8 X 4 GOLD KNOB UP3035 1
41 BENCH FOOT ROLL HOLDER UP0441 1 95 FLAT HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 1/4 BNH0667 2
42 BENCH SLIDE CARRIAGE UP4642 1 96 U-STYLE TAPPED HOLE NUT 3/8-16 BNH1211 2
43 BENCH SEAT PAD UP0444 1 97 DECAL-SIMPLEX II (1 7/8 X 5 3/16) BNH1199 1
44 BENCH BACK PAD UP0445 1 98 DECAL-TUFFSTUFF (2 3/4 X 19 1/16) BNH1200 1
45 WEAR COVER (OPTIONAL) UP0833 1 99 DECAL-EXERCISE SP-403 MULTI- PRESS 4 1/2 X 19 1/4 BNH1188 1
46 FOOT ROLL 1 X 5 1/2 X 7 1/4 UP0350 2 100 DECAL-LARGE TUFFSTUFF LOGO DIAMOND SHAPE BNH0360 1
47 PLASTIC INSERT CAP "A" 1 RD. BNH0812 2 101 DECAL-ADJUST CABLE HERE BNH0789 1
48 PLASTIC INSERT CAP "B" 1 RD. BNH0813 2 102 DECAL-FOR BEST PERFORMANCE 1 1/4 X 1 1/2 BNH0143 1
49 PVC 1 X 7 1/4 BNH1023 2 103 DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1 1/2 BNH0142 2
50 NYLON STEM BUTTON .720" X .187" BNH0533 1 104 DECAL-CAUTION 1 3/4 X 5 1/2 HORIZONTAL BNH0126 1
51 PLASTIC TUBE GUIDE W/LIP-TEETH 2 1/2" SQ. BNH0060 2 105 DECAL-WARNING KEEP HANDS AND FINGERS... BNH0620 1
52 PLASTIC END CAP W/GROOVE 2" SQ. BNH0050 2 106 SUPER LUBE TEFLON LUBRICANT 82340 BNH0704 2
53 PLASTIC END CAP 2 X 3 BNH0606 2
SP-403 Multi-Press
COLOR CHART
GRAY= SUB-ASSEMBLY PARTS
BLACK= HARDWARE
