SPT-6 SIX PACK TRAINER
20
9
20
75
9
75
75
75
47
84
43
47
43
1
20
9
20
75
9
75
75
75
47
84
43
47
43
1
4
Step 3
Assembly List
Item # Description Qty.
1 ADJUSTABLE DOUBLE PULLEY BRACKET 1
9 LONG DOUBLE SWIVEL PULLEY BRKT 2
20 SHORT DOUBLE SWIVEL PULLEY BRKT 2
43 FINISHED HEX NUT B/O 1/2-13 2
47 FLAT WASHER SAE B/O 1/2” 2
75 RETAINING SNAP RING EXT. PLAIN 1 1/4” 4
84 SPLIT LOCK WASHER B/O 1/2” 1
