Section2:OperationalProcedures
2.1InstrumentPanelControlsandIndicators
2.1.1Ford2.5L
Table Operation-2-1, “Instrument Panel Description - Ford 2.5L,” lists the controls, indicators,
and equipment found on the instrument panel for the 660 belt loader with the Ford 2.5L gasoline
engine, and explains the specific function of each. Reference Table Operation - 2 - 1, “Instrument
Panel - Ford 2.5L,” for the location of the items listed.
2.1.2Deutz2.9LTier4F
“Figure Operation - 2 - 2” lists the controls, indicators, and equipment found on the instrument
panel for the 660 Belt loader with the Deutz Tier 4F engine, and explains the specific function of
each. Reference Table Operation-2-2, “Instrument Panel Description - Deutz 2.9L,” for a descrip-
tion of the items shown.
