O W N E R ’ S M A N U A L
•
E 2 5
67
E25
A 233 1095 Meter 1
A 233 1096 Meter, North America
A-1 M5x10 DIN 7985 Screw 4
B 203 1069 Handle bar (incl. B-1, B-3, B-4) 1
B-1 213 1017 Hand grip 2
B-2 533 1090 End plug 2
B-3 403 1161 Pulse grip unit ( B-5--B-7) 2
B-4 513 1008 Tightener 1
B-8 533 1062 Adjuster knob 1
B-9 KB 35x8 WN1411 PT-Screw 2
B-10 M8x75 DIN 603 Screw 1
B-11 523 1034 Sleeve 1
B-12 M6x50 DIN 912 Hex head screw 1
B-13 M5x14 DIN 7985 Screw 2
B-14 103 1081 Base for meter bracket 1
B-15 103 1080 Meter bracket 1
B-16 523 1033 Bushing 2
B-17 M6 DIN 917 Bome nut 2
B-18 M6 DIN 125 Washer 2
C 203 1072 Handle bar post 1
C-1 M8x16 ISO 7380 Hex head screw 2
C-2 403 1174 Meter wire, upper 1
C-3 403 1175 Meter wire, lower 1
D-1 443 1015 Transmission belt 1
D-2 533 1092 Screw-plug (incl. D-3) 2
D-4 17 DIN 471 C-clip 1
D-5 653 1033 Washer 1
D-6 653 1034 Washer 1
D-7 523 409 85 Bearing 2
D-8 40 DIN 472 C-clip 2
D-9 343 1016 Axle for pulley 1
D-10 M8x12 DIN 933 Allen head screw 3
D-11 263 1017 Pulley 1
D-12 353 1018 Crank R 1
- 353 1019 Crank, L 1
E 403 1176 Servo motor compl. 1
F 303 1023 Flywheel, compl.
(incl.F-1,F-2,F-4,F-5,F-9,F-10) 1
F-3 M6x12 DIN 931 Screw 1
F-6 523 1036 Bearing house 2
F-7 M5x14 DIN 7985 Screw 6
F-8 653 1040 Washer 1
F-11 M6 DIN 127 Spring washer 1
G-1 533 1048 Wheel 2
G-2 673 500 88 Cap 2
G-3 72 0813 100 1 Sleeve 2
G-4 M5x14 DIN 7500C Screw 7
G-5 KB 40x40 WN1412 PT-Screw 3
G-6 M5x14 DIN 7985 Screw 4
G-7 373 1053 Locking knob 1
G-8 M5x8 DIN 7500C Screw 1
G-9 533 1085 Release switch 1
G-10 693 1010 Slide piece, pair 1
G-12 403 1077 Sensor switch 1
G-13 653 1042 Screw 1
H-1 103 1077 Front support 1
H-2 653 1039 Washer 4
H-3 533 1086 Adjuster foot 4
H-4 533 1067 Front foot cover, 1
H-5 KB 40x40 WN1412 PT-Screw 12
H-6 M5 DIN 125 Washer 12
H-7 173 11122 Rear support cover, 2
H-8 103 1078 Rear support 1
I-1 M8 DIN 985 Nylock nut 2
I-2 513 1013 Belt tightener frame 1
I-3 523 1029 Bearing 2
I-4 M8 DIN 125 Washer 2
I-5 M8x20 DIN 933 Screw 1
I-6 643 1016 Spring 1
J 363 1010 Pedal, pair 1
K-1 153 1043 Seat 1
K-2 153 1041 Seat clamp, set (incl. K-5) 1
K-3 M8x65 DIN 913 Locking screw 1
K-4 153 1057 Seat tube 1
K-6 373 1047 Locking screw (incl.K-7,K-8) 1
M-1 173 1116 Side cover, LH 1
M-1 173 1161 Side cover, LH, North America
M-2 173 1117 Front cover 1
M-3 173 1118 Front plate 1
M-4 173 1115 Side cover, RH 1
M-4 173 1162 Side cover, RH, North America
M-5 173 1119 Side cover end plug 2
M-5 173 1163 Side cover end plug,North America
M-6 173 1120 Seat tube cover 1
N-1 M8 DIN 9021 Washer 8
N-2 M8x16 DIN 7985 Screw 8
O 403 1178GB Transformer GB 1
O 403 1178EU Transformer EU 1
O 403 1178US Transformer US 1
O 403 1178AUS Transformer AUS 1
- 423 1172 Label set 1
- 553 1015 Hardware kit (incl *) 1
- 553 101 88 Screw - shaped 1
- 553 100 88 Multi purp. wrench 1
- 556 032 00 Allen key 6 mm 1
- 583 1058 Owner’s manual 1
- 583 0006 Warranty booklet 1
