No. Description QTY
1 Console 1
2 Screw M5x10 3
3 Console bracket 1
4 Console bracket seat 1
5 Sleeve Ø6.0*Ø9.8*50L 1
6 Screw M6xP1.0x60L 1
7 Fixed washer 2
8 Nylon nut M6 1
9 Console locking knob 1
10 Fixed washer 1
11 Handlebar 1
12 Foam grip 2
13 Hand pulse sensor 2
14 Hand pulse sensor wire 1
15 Screw M4x20 2
16 End cap 2
17 Handlebar tightener 1
18 Handlebar post 1
19 Console cable, upper 1
20 Screw M5x20 2
21 Bottle holder 1
22 Main frame 1
23 Nyloc Screw M8x12L 3
24 Driving pulley 1
25 Axle 1
26 Bushing 1
27 Screw M10x50L 2
28 Nyloc screw M8x20L 2
29 Seat post knob 1
30 Crank, L 1
31 Crank, R 1
32 Nut M17 1
33 Flate washer 1
35 Seat post sleeve 1
36 Bearing 6203 2
37 Sensor fixed bracket 1
38 Flat washer 2
39 Screw M4x16L 3
40 Sensor wire 1
41 Connection wire (flywheel &
control board)
1
42 Driving belt 1
43 Side cover, left 1
44 Side cover, right 1
45 Crank cap 1
46 Top cover 1
47 Seat post cover 1
48 Cover of bottom tube 1
49 Handlebar post cover 1
50 Handlebar post ring 1
51 Shaft of chain cover 2
52 Screw M4x10L 3
53 Screw M5x16 8
54 Pedal, pair 1
55 Power supply wire 1
56 Fixed tube of semi-bracket 2
57 Seat post 1
58 Horizontal sliding tube 1
59 Fixed screw 7/16"-14 1
60 Flat washer Ø12.5xØ20x2t 1
