Replacement Parts List
22
When ordering replacement parts, please quote the part number and the description as listed below. If the part required
is not listed below, request the part by description and quote model number and serial number which is shown on the
Technical Data Plate.
Important:
Only genuine authorized replacement parts should be used for the servicing and repair of this oven. The instructions
supplied with the parts should be followed when replacing components.
For further information and servicing instructions, contact your nearest authorized service provider or Turbofan Dealer.
Item Description
236256 Digital Control Board Kit.
234450 Encoder.
234447 Control Knob.
234429 Transformer, 208 / 240V x 12V AC SEC, 20VA.
234460 Cooling Fan 230V.
237447K Temperature Probe Kit PT1000
234821 Overtemp Thermostat 355°C / 670°F.
231738 Contactor - Heating.
231742 Contactor - Motor Speed.
236109 Oven Element, 5800W, 230 - 240V.
236110 Oven Element, 5800W, 208 - 220V.
236264 Element Gasket (included in Oven Element Kit).
235625 Fan Motor, 2 Speed.
235610 Motor Shaft Seal.
234138 Fan - Dia 8½” / 220mm.
236053 Motor Capacitor 6.3uF, 60Hz Only.
236054 Motor Capacitor 8uF, 50Hz Only.
021352 Oven Glass Lens.
231814 Lamp Bulb G9 25W, Halogen, 230V.
021354 Oven Lamp Gasket.
234803 Fuse 10A, 250V.
020851 Water Solenoid.
021057 Spray Nozzle Assembly.
235615 Oven Door Seal - E33.
235652 Door Inner Glass Assembly.
235859 Door Handle Assembly.
231804 Single Step Locking Dog.
235851 Door Hinge Set Top
235852 Door Hinge Set Bottom
232379 Foot Adjustable (73 - 80mm).
232380 O-Ring.
235669 Side Rack LH, 5 Tray - E33.
235670 Side Rack RH, 5 Tray - E33.
236057 Oven Rack - E33.
Item Description
236060 Core Temperature Probe Kit.
235845 Core Temperature Probe.
235847 Dust Cap - Core Temperature Socket.
236271 Core Temperature Probe Holder.
Optional Extras
