High and Lowpass filter Screens
Each output has an independent high pass filter and an independent low pass filter. Both filters
have a range of selectable slopes, which are Bessel 12dB, 18dB and 24dB, Butterworth 12dB, 18dB
and 24dB, and Linkwitz Riley 24dB.
Highpass filters have a range of <10Hz (through) to 16kHz and Lowpass filters have a range of
22kHz (through) to 59Hz in 1/36 octave steps.
HPFs and LPFs can be asymmetrical set.
To adjust HPF/LPF settings:
To adjust HPF/LPF settings:To adjust HPF/LPF settings:
To adjust HPF/LPF settings:
Use the
‘FREQ’
‘FREQ’‘FREQ’
‘FREQ’ control for the frequency.
Use the
‘Q’
‘Q’‘Q’
‘Q’ control for the slope.
OP1+4 Low HPF
< 10Hz Bessel 24dB
