Specifications
Inputs
InputsInputs
Inputs Two electronically balanced 
Impedance > 10k ohms
CMRR >65dB 50Hz - 10kHz
Outputs
OutputsOutputs
Outputs Six electronically balanced 
Source Imp < 60ohms
Min. Load 600ohms
Max. Level +20dBm into 600 ohm load
Frequency Resp
Frequency RespFrequency Resp
Frequency Resp. ±0.5dB 20Hz - 20kHz
Dynamic Range
Dynamic RangeDynamic Range
Dynamic Range >110dB 20Hz -20kHz. Unwtd
Distortion
DistortionDistortion
Distortion < 0.02% @ 1kHz, +18dBm
Maximum Delay
Maximum DelayMaximum Delay
Maximum Delay 650 mS. (Increment 2.
..
.6 µS)
Output gain
Output gainOutput gain
Output gain adjustable +15dB to -40dB in 0.1dB steps and mute
Input gain
Input gainInput gain
Input gain Adjustable +6dB to -40dB in 0.1dB steps
Parametric Equalisation
Parametric EqualisationParametric Equalisation
Parametric Equalisation
Filters 5 Sections per output
Filter gain +15dB to -30dB in 0.1dB steps
Centre frequency 20Hz - 20kHz, 1/36 octave steps. (368 positions)
Filter Q / BW 0.4 to 128 / 2.5 to 0.008
(Sections switched to shelving response)
(Sections switched to shelving response)(Sections switched to shelving response)
(Sections switched to shelving response)
Low frequency 20Hz - 1kHz
High frequency 1kHz - 20kHz
Shelf gains ±15dB in 0.1dB steps
High and Lowpass Filters
High and Lowpass FiltersHigh and Lowpass Filters
High and Lowpass Filters
Filters 1 of each per output
Frequency (HPF) 10Hz - 16kHz, 1/36 octave steps
Frequency (LPF) 60Hz - 22kHz, 1/36 octave steps
Response Bessel / Butterworth 12/18/24dB /oct and Linkwitz-Riley 24dB /oct
Limiters
LimitersLimiters
Limiters
Threshold +22dBu to -10dBu
Attack time 0.3 to 90 milliseconds
Release time 4, 8, 16 or 32 times the attack time
Display
DisplayDisplay
Display 2 x 20 character backlit LCD
Input meter
Input meterInput meter
Input meter 2 x 6 point, -24dB to digital clip
Output meter
Output meterOutput meter
Output meter 6 x 6 point, -24dB to +4dB into limit
Connectors
ConnectorsConnectors
Connectors
Inputs 3 pin female XLR
Outputs 3 pin male XLR.
Power 3 pin IEC
Power
PowerPower
Power 60 to 250V ±15% @ 50/60Hz
Consumption
ConsumptionConsumption
Consumption < 20 watts.
Weight
WeightWeight
Weight 3.5kg. Net (4.8kg. Shipping)
Size
SizeSize
Size 1.75"(1U) * 19" * 11.8" (44 * 482 * 300mm) excluding connectors.
Options
OptionsOptions
Options  = Transformers available.
Due to continuing product improvement the above specifications are subject to change.
