APPENDIX B
Technical Specifications
TQ-310 TQ-315
Dimensions 525mm x 319mm x 277mm
(20.7” x 12.5” x 10.9”)
691mm x 443mm x 381mm
(27.2” x 17.4” x 15”)
Net weight 21kgs (46.2lbs) 35.5kgs (78.1lbs)
Components 1 x 10” (254mm) LF driver
1 x 1” (25mm) HF compression
driver
1 x 15” (381mm) LF driver
1 x 3” diaphragm (35mm) HF
compression driver
Frequency
response
65Hz – 20kHz ±4dB (with digital
controller)
55Hz – 20kHz ±4dB (with digital
controller)
Nominal
dispersion
100°H x 60°V @-6dB points 80°H x 50°V @-6dB points
Sensitivity 96dB, 1 watt @ 1 metre 99dB, 1 watt @ 1 metre
Power handling 350 watts r.m.s., 700 watts
program, 875 watts peak
LF: 600 watts r.m.s., 1200 watts
program, 1500 watts peak
HF: 80 watts r.m.s., 160 watts
program, 200 watts peak
Maximum SPL 124dB continuous, 130dB peak 130dB continuous, 136dB peak
Construction 12mm (1/2”) birch plywood
throughout; rebated, screwed and
glued. Finished in black semi-matt
textured paint.
15mm (5/8”) birch plywood
throughout; rebated, screwed and
glued. Finished in black semi-matt
textured paint.
Grille Reticulated foam on expanded steel
mesh
Reticulated foam on expanded steel
mesh
Connectors (2) Neutrik Speakon NL4MP
wired pin 1+: +ve, pin 1-: –ve
(2) x Neutrik Speakon NL4MP, wired
pin1+:+ve, pin 1-: -ve. Active: pin1+:
LF+; pin 1-: LF-; pin2+: HF+, pin2-: HF-
Options TurboBlue semi-matt textured
paint
TurboBlue semi-matt textured paint
Due to continuing product improvement the above specifications are subject to change.
