Turbosound TFM Series User Manual

30 TFM Series Quick Start Guide 31
Specications
TFM122M TFM152M
System
Frequency response
70 Hz – 18 kHz ±3 dB
63 Hz – 20 kHz -10 dB
65 Hz – 18 kHz ±3 dB
50 Hz – 20 kHz -10 dB
Nominal dispersion 60° H x 40° V @ -6 dB points, rotatable 60° H x 40° V @ -6 dB points, rotatable
Directivity factor (Q) 18.3 18.3
Directivity index (DI) 12.6 12.6
Power handling (IEC)
Passive 350 W continuous, 1,400 W peak 350 W continuous, 1,400 W peak
Bi-amp
LF: 310 W continuous, 1,240 W peak
HF: 40 W Continuous, 160 W peak
LF: 310 W continuous, 1,240 W peak
HF: 40 W Continuous, 160 W peak
Sensitivity 96 dB (1 W @ 1 m) 98 dB (1 W @ 1 m)
Maximum SPL
Passive 122 dB continuous, 128 dB peak 124 dB continuous, 130 dB peak
Bi-amp
LF: 121 dB continuous, 127 dB peak
HF: 123 dB continuous, 129 dB peak
LF: 123 dB continuous, 129 dB peak
HF: 123 dB continuous, 129 dB peak
Impedance
Passive 8 Ω 8 Ω
Bi-amp
LF: 8 
HF: 8 
LF: 8 
HF: 8 
Crossover type Passive / bi-amp switchable Passive / bi-amp switchable
Components
1 x 12" (315 mm) LF driver
1 x 1.4" (33 mm) HF compression driver
1 x 15" (393.5 mm) LF driver
1 x 1.4" (33 mm) HF compression driver
Enclosure
Connectors 2 x Neutrik speakON NL4 2 x Neutrik speakON NL4
Wiring
Passive Pins 1+ / 1- input, pins 2+ / 2- link Pins 1+ / 1- input, pins 2+ / 2- link
Bi-amp Pins 1+ / 1- LF, pins 2+ / 2- HF Pins 1+ / 1- LF, pins 2+ / 2- HF
Dimensions (H x W x D) 302 x 452 x 504 mm (11.9 x 17.8 x 19.9") 351 x 530 x 565 mm (13.8 x 20.9 x 22.3")
Net weight 15.5 kg (34.1 lbs) 19.4 kg (42.7 lbs)
Construction 15 mm (⁄") birch plywood+Polypropylene plastic 15 mm (⁄") birch plywood+Polypropylene plastic
Finish Semi-matt black paint Semi-matt black paint
Grille Powder-coated perforated steel Powder-coated perforated steel
Flying hardware N/A N/A
