7
2016/12
Technical data (s. also page 10)
Operating voltage: 24 ± 10 % VDC
Current consumption: < 100 mA
Switching output: PNP, NO/NC
progr.
Switching current: < 200 mA
Aalogue output: 4…20 mA
Last R
L
: 200…500 Ω
Operating range:
depending on device (s. page 10)
Temperature monitoring: -10…90 °C
If ow rate monitoring is selected for S1
Adjustable range for S1 [l/min]: depending on device (s. page 10)
Hysteresis for S1 [l/min]: depending on device (s. page 10)
If temperature monitoring is selected for S1
Adjustable range for S1: -9…+90 °C
Hysteresis for S1: 1…10 °C
Parameterisation
Switch-on delay: 0…50 s
Switch-o delay: 0...50 s
Availability time: 6...10 s
Response time: 1…8 s
Housing material: PBT
Flow rate display: 7-segments/3 digits
Connection: 4-pole, M12 x 1
Parameter Parameter value Function
0 Cod 0…255 Enter access code Factory setting 0
1 USP L or °C Unit switch point S1 [l/min oder °C]
2 SP MIN +0,2…MAX
or -9…90
Adjustable range switch point S1 [l/min or °C] (see page 10)
3 hS 0,2…2/5/10
or 1…10
Hysteresis switch point S1 [l/min or °C] (see page 10)
4 OU nO or nC Output switch point S1 [N.O./N.C.]
5 dS 0…50 Switch-on delay switch point S1 [s]
6 dr 0…50 Switch-o delay switch point S1 [s]
7 nFi 1, 2, 4, 8 Average value [s]
8 GLY 0…30 Selection of glycol contents in 5-%-Steps
9 CAL Display correction [+/-25 %]
10 Cod 0…255 Modication of access codes
Disposal
Devices must be properly disposed of, not in general household waste.
Manufacturer and Service
Turck supports you with your projects, from initial analysis to the commissioning of your application. The Turck product database contains
software tools for programming, configuration or commissioning, data sheets and CAD files in numerous export formats. You can access the
product database at the following address: www.turck.de/products/
Should you have any further questions, please contact the sales and service team in Germany on the following telephone numbers:
Sales: +49 208 4952-380
Technology: +49 208 4952-390
Outside Germany, please contact your Tûrck representative.
Hans Turck GmbH & Co. KG
Witzlebenstraße 7
45472 Mülheim an der Ruhr
Germany
