85363-85364 Rev B
Intended Use: The LS–22 Lawn Seeder is intended to be USED ONLY to apply grass seed turf at a
properly prepared worksite. The LS–22 Lawn Seeder is intended only to be used with grass seed. The LS–22
Lawn Seeder is NOT intended to be used for any purpose other than to apply grass seed to the turf. The
LS–22 is not intended to be used for the application of fertilizers or lawn foods. The LS–22 is not intended
to be used as a lawn rake/sweeper, lawn aerator, or a rototiller. The LS–22 is not designed for or intended to
accept riders.
Hopper Capacity ......................................................0.02 Cubic Meter (1,252 Cubic In. or 0.72 Cubic Ft.)
Hopper Seed Weight Capacity ...............................
Approximately 13.6 Kilograms (30 Pounds)
Seed Application Width ..........................................
50.8 cm (20” Inches)
Seed Gate .................................................................Variable Opening, Controlled at Operator Position
Recommended Ground Operating Speed .............Pushed By Hand @ 4.0 Km/h (2.5 MPH)
Blade Assembly .......................................................14 Blade Sets, Total 28 Blades
Blade Assembly Maximum Operating Depth ........
Up to 38 mm (1.5” Inches)
Blade Rotation .........................................................Forward Rotation
Engines
85363 ..................................................................4.10 kW (5.5 HP) Honda GX160
85364 ..................................................................4.10 kW (5.5 HP) Briggs and Stratton Vanguard
Drive and Clutch ......................................................V-Belt Drive, Idler Tension V-Belt Clutch
Wheels/Tires ............................................................410/350 x 4” Inch Pneumatic Tires
LS–22 Dimensions (Handlebars Folded):
Width ...................................................................
83.8 cm (33” Inches)
Height ..................................................................
88.9 cm (35” Inches)
Length .................................................................
107.9 cm (42.5” Inches)
LS–22 Dimensions (Handlebars Unfolded):
Width ...................................................................
83.8 cm (33” Inches)
Height ..................................................................119.4 cm (47” Inches)
Length .................................................................111.8 cm (44” Inches)
Weight (Dry) .............................................................
86.1 Kg (190 Pounds)
Maximum Weight With Seed Hopper Full .............
99.8 Kg (220 Pounds)
Specifications
Noise and Vibration Levels
Vibration Level:
Handlebar at Operator Position
Vibration, Linear = 1.26 m/sec2 RMS
Vibration, Weighted = 0.23 m/sec2 RMS
Test Conditions:
Engine Full Throttle, Blade Assembly
Operating and Lowered to 6.3 mm (1/4”)
Cut, Seed Hopper Empty, Unit Moving.
Noise Emission Level:
Operator Position
Sound Pressure (LpA) = 86.2 dBA
Sound Pressure Level (LwA) = 98.1 dBA
Test Conditions:
Engine Full Throttle, Blade Assembly
Operating, Unit Stationary.
The Engine Exhaust From This Product Contains Chemicals Known to the State of California
To Cause Cancer, Birth Defects or Other Reproductive Harm.
ONLY OPERATE ENGINE IN AREAS WITH ADEQUATE VENTILATION.
DO NOT OPERATE ENGINE IN ENCLOSED AREAS.
LpA = 86.2 dBA
LwA = 98.1 dBA
SPECIFICATIONS
