Turtle Beach Ear Force TM1 - Connector Types; Function Map; Connection Types; Front View

2
Connection Types
Front View
Channels 1-6
1. 3.5mm Mic Input
2. 9-Pin DIN
3. USB Pass-through Connection
4. 3.5mm Headphone Output
Connector Typess/ Function Map
4
21
3
4 Pole Connector
Pink Mic Cable
Green 3 Pole Stereo Connector
mic
ground
right
left
ground
right
left
ground
mic
Stereo PC Headset to
4 Pole Converter Cable
4 Pole to Stereo PC
Headset Mic Converter
