Turtle Beach Ear Force TM1 - Top View

4
Top View
1. Analog Game Level Controls: For use with analog setup;
controls game sounds only, with no effect on mic. or chat level.
Adjust game level to taste. This does not affect game volume
when the optical connection is used.
2. Mic. Output Level Controls (Inner Knob), Mic. Noise Gate
(Outer Knob): Mic. level controls the gain on an outgoing mic.
Adjust mic. level to taste. Noise gate is not affected by mic. level.
3. Analog Chat Level Controls: For use with analog setup; controls
analog chat level only, with no effect on game sounds. Adjust
chat level to taste.
3. Analog Chat Level Controls: For use with analog setup; con-
trols analog chat. level only, with no effect o
Function Map
1
2
3
