Tuxedo TP9KF - Page 23

２２
TP9KF
July 2015-A
ITEM DESCRIPTION QTY
29 Symm Swing arms L 2
30 Arm pin 4
31 Cross bolt 4
32 Saddle pad weldment 2
33 Symm Swing arm R 2
34 Hex bolt C 4
35 Nut 4
36 Flat washer 4
37 Spring washer 4
38 Power unit 1
39 Washer 1
40 Hydraulic fitting 1
41 Elbow fitting 1
42 Hydraulic hose, short 1
43
Elbow fitting
1
44 Pipe nipple 1
45 Hydraulic Hose, long 1
45.1 Hydraulic fitting, 45 degree 2
46 Carriage 2
47 Nylon block 16
48 Shaft sheath 2
49 Flat washer 2
50 Safety Latch 2
51 Pull Spring 2
52 Inner hex bolt 2
53 Spring 2
54 Pull wire 2
55 Plastic sheath 2
59 Hydraulic cylinder 2
60 Spindle 2
61 Idler wheel 2
62 Spindle spring washer 2
