TVLogic LVM-241W User Manual

6
LVM-171W / 241W / 401W / 461W / 571W
Name & Function of Each Part
<FRONT>
FACTORY PGM
CVBS1/Y/G/S-Y
CVBS2/Pb/B
CVBS3/Pr/R/S-C
DVI-I
SDI IN-A
SDI OUT-A
SDI IN-B
SDI OUT-B
AC IN
<REAR>
HDMI
RS485 OUT
RS485 IN
REMOTE
AUDIO IN
AUDIO OUT
ANALOG INPUT
SDI INPUT SELECT
UNDER SCAN
ASPECT
MARKER
H/V DELAY
STAND BY
ENTER
UP / CONTRAST
DOWN / BRIGHT
MENU
CHROMA/PHASE
BLUE ONLY / MONO
TALLY
(LVM-171W / LVM-241W)
