TVS Jupiter ZX User Manual

7
7
INTEGRATED STARTER
GENERATOR (ISG)
‘Integrated Starter Generator’ (ISG)
system has delivers a noiseless
start of the vehicle. An ISG
malfunction indicator is also added
to the speedometer.
'TVS intelliGO'
An intelligent start/stop system that
further enhances fuel efficiency.
Easy on your pocket and kinder to
the environment. Refer page No.
27 for details.
LOW FUEL INDICATOR
‘Low Fuel Indicator’ is yet another
unique feature of your scooter which
indicates you to refill the fuel, when
the fuel in the tank goes below
minimum safe level. Refer page No.
29 for details.
ALL IN ONE LOCK
Your scooter has all in one lock that
unlocks the seat and fuel tank cap
at the ignition lock itself. Refer page
No. 24 for details.
UNIQUE PASS-BY SWITCH (First
Time in Scooters)
Pass-by Switch is a feature first time
introduced in scooters ever. It allows
you to easily switch between high
& low beam of the head lamp with
easy press and auto release. It is
helpful especially while overtaking.
Refer page No. 59 for details.
'TVS intelliGO' SWITCH
An exclusive intelliGO switch is
provided to switch OFF and ON
the intelliGo system as and when
required. Refer page No. 60 for
details.

TVS Jupiter ZX Specifications

General

Engine Capacity	109.7 cc
Front Brake	Drum
Rear Brake	Drum
Kerb Weight	109 kg
Front Suspension	Telescopic
Tyre Type	Tubeless
Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Transmission	CVT
Tyre Size (Front)	90/90-12
Tyre Size (Rear)	90/90-12
Length	1834 mm
Height	1115 mm
Seat Height	765 mm
Ground Clearance	150 mm
Wheelbase	1275 mm
Maximum Torque	8.4 Nm @ 5000 rpm
Brakes	Drum
Rear Suspension	Hydraulic
Starting Method	Electric Start
Max Torque	8.4 Nm @ 5000 rpm
Wheel Size	12 inches
