10
3
9
2
1
86
7
54
LOCATION OF PARTS - SIDE VIEW L
Description:
1. Position lamp
2. Head lamp assembly
3. Turn signal lamp L
4. Carburettor
5. Gear shifting lever
6. Side stand
7. Center stand
8. Pillion footrest L
9. Seat lock
10. RC lamp assembly
KNOW ABOUT YOUR NEO
16

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TVS NEO Series and is the answer not in the manual?

TVS NEO Series Specifications

General IconGeneral
Engine TypeSingle Cylinder, 4 Stroke, Air Cooled
Displacement109.7 cc
Tyre TypeTubeless
Transmission4 Speed
Fuel Tank Capacity10 liters
BrakesDrum
Front SuspensionTelescopic
Rear SuspensionHydraulic Shock Absorber
