TVS NEO Series User Manual

Fuse
Fuse is located just below the utility box, to
access the open the seat. Inside the utility box
a lid is provided to access the fuse. Replace
fuse with the spare fuse given in the fuse box
if fuse is blown.
Fuse 10 A
Air filter
Neo air filter has a paper filter element.After
removing the side panels, remove the air
filter from the bike. Separate the air filter
cover using a screw driver and takeout the
filter element.Clean the paper element using
a compressed air as shown. After cleaning,
MAINTENANCE
46

TVS NEO Series Specifications

General

Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Displacement	109.7 cc
Tyre Type	Tubeless
Transmission	4 Speed
Fuel Tank Capacity	10 liters
Brakes	Drum
Front Suspension	Telescopic
Rear Suspension	Hydraulic Shock Absorber
