2. Remove gauge oil level (Dipstick) from the
cover clutch.
3. Wipe off the oil from dipstick and insert to
the oil filling orifice. Now take out and
check for engine oil level. The level should
be between minimum and maximum
level.
4. Repeat previous steps once again to
confirm oil level. Reassemble the dipstick
and tighten.
Engine oil replacement:
1. Warm up the engine for few minutes.
Repeat the first two steps of oil level check.
2. Remove the oil drain plug using a 17 mm
spanner. Carefully drain the oil into a
pan/tray. While removing drain plug filter
oil also comes out along with.
3. Clean the filter oil with compressed air and
refit.
4. Reassemble the drain plug.
MAINTENANCE
Running engine with very low engine oil will
severly damge the engine components.
G
Maximum level
Minimum level
49

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TVS NEO Series and is the answer not in the manual?

TVS NEO Series Specifications

General IconGeneral
Engine TypeSingle Cylinder, 4 Stroke, Air Cooled
Displacement109.7 cc
Tyre TypeTubeless
Transmission4 Speed
Fuel Tank Capacity10 liters
BrakesDrum
Front SuspensionTelescopic
Rear SuspensionHydraulic Shock Absorber
