LOCATION OF PARTS - VEHICLE FRONT & REAR
FRONT
1. Turn signal lamp front L
2. LED headlamp assembly
3. Turn signal lamp front R
REAR
1. Tail lamp assembly
2. Turn signal lamp rear R
3. Reflex reflector
4. Turn signal lamp rear L
1
1
2
4
3
3
2
