TVS RAIDER - Control Key and Ignition; Ignition and Steering Lock

18
CONTROL KEY
TVS Raider 125 comes with a pair of identical control
keys. These keys are to operate ignition cum steering
lock, fuel tank cap and seat lock.
IGNITION CUM STEERING LOCK
There are three positions in the ignition cum steering
lock. They are:
1. ‘OFF’ position
All the electrical circuits are turned ‘OFF‘ in this
position. Engine will not start. Key can be taken out.
2. ‘ON’ position
In this position, all the electrical circuits are turned
‘ON’ and the engine can be started. Key cannot be
removed.
3. ‘LOCK’ position
TVS Raider 125’s steering can be locked in both ‘left’
and ‘right’ directions. To lock the steering, turn the
handle bar all the way to the ‘left’ or ‘right’ direction.
Push the key ‘IN’ and turn it to the ‘LOCK’ position
and take out. All the electrical circuits are turned
‘OFF’ in this position.
Insert the key into the lock and turn it to ‘OFF’ or ‘ON’
position to unlock the steering.
Never attempt to move the vehicle when the steering is
locked, you may lose balance.
Warning
Before turning the ignition key to ‘ON’ position, ensure
the availability of adequate fuel in the tank to avoid dry
run of fuel pump. Fuel level always to be maintained
above single bar.
Never run the fuel pump dry to avoid failure of fuel
pump.
Leaving the ignition cum steering lock in ‘ON’ position
will drain the battery when the vehicle is not in use.
Switch ‘OFF’ and take the key out when the vehicle is
not in use.
Caution
