58
REAR BRAKE PEDAL
Rear brake pedal is located on the right side of the
vehicle. Press the rear brake pedal with your right
foot to apply the rear brake. The front brake also will
be applied while applying the rear brake. The brake
lamp glows on application of brake.
CENTRE STAND AND SIDE STAND
TVS Raider 125 is equipped with a centre (1) and side
stand (2). To place the vehicle on the centre stand,
hold the handle bar left grip with left hand and pillion
handle with right hand.
Place your foot firmly on the centre stand extension
(1a) and press with adequate effort. Ensure both the
legs of centre stand are touching the ground before
placing the vehicle on the stand.
Side stand can be operated by sitting on the vehicle
with your left foot by pushing it away from the vehicle
till it stops.
Brakes are items of personal safety and should always
be maintained in proper condition.
1a
1
2
