TVS WEGO User Manual

MANUFACTURER : TVS MOTOR COMPANY LIMITED
P.B. No 4, Harita, Hosur - 635 109, India.
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
ENGINE
Type : Single cylinder, 4 stroke, air
cooled, spark ignition engine
Cylinder bore : 53.5 mm
Stroke : 48.8 mm
Piston displacement : 109.7 cc
Compression ratio : 9.5 : 1
Carburettor : UCAL VM 16 SH
Air filter : Viscous paper filter
Lubrication system : Forced wet sump
Maximum power in kW : 5.88 @ 7500 rpm
Maximum torque in Nm : 8.4 @ 5500 rpm
Maximum speed : Around 78 km / hr
Engine idling rpm* : 1600 + 100 rpm
Starting system : Electric starter / kick starter
TRANSMISSION
Clutch : Dry - Centrifugal clutch
Primary transmission : CVT (Continuous Variomatic
Transmission)
Primary reduction : 2.38 to 0.82
Final reduction : 10.47
CHASSIS
Dimensions and weights
Overall length : 1834 mm
Overall width : 640 mm
Overall height : 1115 mm
Ground clearance : 132 mm
Wheel base : 1275 mm
Steering angle : 90°
Caster angle : 25°
Kerb weight
(with tool kit & 90% of fuel) : 108 kg
Pay load : 130 kg
Maximum laden weight : 238 kg
Frame : Duplex tubular frame
Front suspension : Telescopic hydraulic
Rear suspension : Toggle link, gas filled hydraulic
dampers
Trail length : 93 mm
BRAKES
Front Disc : 220 mm dia (hand operated)
Drum : 130 mm dia (hand operated)
Rear : 130 mm dia (hand operated)
-59-
* Under warm condition

TVS WEGO Specifications

General

Displacement	109.7 cc
Fuel System	Carburetor
Transmission Type	CVT
Front Brake	Drum
Rear Brake	Drum
Front Suspension	Telescopic
Rear Suspension	Unit Swing with Spring Loaded Hydraulic Damper
Cooling System	Air-cooled
Tyre Size (Front)	90/90-12
Tyre Size (Rear)	90/90-12
Seat Height	770 mm
Ground Clearance	150 mm
Wheelbase	1275 mm
Engine Type	4-stroke, Single Cylinder
Maximum Power	8.1 bhp @ 7500 rpm
Fuel Tank Capacity	5 Litres
