Operation manual T24N
9
2.3 Operating modes
The T24N loudspeaker has a switch (see figure 2.3) on the back for switching between two
different operating modes (see figure 2.1, no. 10).
In the „PASSIVE“ mode, the loudspeaker is operated on a passive audio crossover with a
single amplifier channel.
In the „BIAMP“ mode, the internal passive crossover is being by-passed, therefore the
low-frequency section (2×12“) and high-frequency (1×1,4“) section must be driven separately
by individual processed amplifier chan-nels.
Figure 2.3 - selector switch
Never change the operating mode while the loudspeaker is connected. In addition to setting
the switch, the corresponding preset on the amplifier must be changed.
Operating with an incorrect preset can damage parts of the loudspeaker.
