Twin Eagles TEGH48 - User Manual

Questions and Answers

B
Brian AguilarAug 14, 2025
What to do if the Twin Eagles TEGH48 igniter sparks but the pilot burner won't ignite?
- K
  Kenneth PettyAug 14, 2025
  If the igniter of your Twin Eagles Patio Heater sparks, but the pilot burner doesn't ignite and the igniter locks out, it might be due to a few reasons. First, check if the gas supply valve is turned on. Another common issue, especially during the initial setup, is air trapped in the gas line. Try turning on the remote control three times to purge this air. If that doesn't work, disconnect the gas hose from the heater inlet and purge air until you smell gas, then reconnect the hose.
J
John ScottAug 18, 2025
Why is my Twin Eagles Patio Heater remote control not communicating with the heater module?
- B
  Brian FrankAug 18, 2025
  If your Twin Eagles Patio Heater's remote control isn't communicating with the heater module, there are several potential causes. First, try replacing the batteries in the transmitter with two new 3V lithium batteries. If that doesn't solve the problem, open the control panel and check if the battery pack is plugged in, or replace the four AA batteries. Also, ensure that the module switch is set to REMOTE. If none of these steps work, you may need to synchronize the remote with the module, referring to the manual for instructions.
D
Donna KelleyAug 20, 2025
How to fix a Twin Eagles Patio Heater valve that won't switch from Hi to Low?
- J
  Jake PerezAug 20, 2025
  If the heater valve on your Twin Eagles Patio Heater won't switch between Hi and Low, it could be due to a low battery pack. Try replacing the four AA batteries. Another potential issue is a disconnected ground wire. Connect the ground wire to the chassis, then remove and reinstall the four AA batteries to clear the memory. If these steps don't resolve the problem, the gas valve may be defective, and you should contact your local dealer for a replacement.
M
Melissa HowardAug 25, 2025
What to do if Twin Eagles TEGH48 Patio Heater beeps but there are no sparks to pilot?
- N
  Nathan RoseAug 25, 2025
  If the remote control communicates with your Twin Eagles Patio Heater, but the heater beeps and there are no sparks to the pilot, it could be because the pilot sensor is damp or wet, so ensure the installation is in a dry location. It could also be a defective pilot sensor, in which case you should replace the pilot burner assembly. Also, check the battery pack and replace the 4 AA batteries if they are low.
T
Trevor ThomasAug 27, 2025
Why does my Twin Eagles Patio Heater igniter give weak sparks?
- I
  Ian LongAug 27, 2025
  If the igniter on your Twin Eagles Patio Heater gives very weak or slow sparks, the battery in the battery pack might be low. Open the heater control panel and replace the four AA batteries. Another possible cause is a disconnected ground wire. With the control panel open, check if the green wire is grounded.
M
Morgan CarrAug 30, 2025
Why does my Twin Eagles Patio Heater pilot and burner turn on and off?
- D
  David BarnesAug 30, 2025
  If the pilot and burner on your Twin Eagles Patio Heater are turning on and off, it could be due to windy conditions. Do not operate the equipment until the wind dies down, or relocate the heater to a less windy area. Another possible cause is that the pilot flame is too small for flame sensing. Increase the pilot flame so that it surrounds the pilot sensor rod. Also, ensure the heater is installed correctly with the gas inlet on the left side for proper operation, ensuring the pilot sensor is positioned correctly relative to the pilot flame.
C
Candice WilcoxSep 3, 2025
Why does my Twin Eagles TEGH48 Patio Heater make continuous beeps?
- L
  Lisa HuntSep 3, 2025
  If your Twin Eagles Patio Heater operates but makes continuous beeps, the module may be exceeding its designed operating temperature. Ensure correct installation so that only radiant heat passes through the front grille.
T
Tracy MillerSep 6, 2025
Why do the batteries in my Twin Eagles TEGH48 Patio Heater battery pack drain fast?
- F
  frederickschneiderSep 6, 2025
  If the batteries in your Twin Eagles Patio Heater's battery pack are draining quickly, ensure the battery pack switch is set to LATCHING SOLENOID instead of DC MOTOR.
D
Darlene OliverSep 10, 2025
Why does the front grille of my Twin Eagles Patio Heater deteriorate?
- D
  Diane BuckSep 10, 2025
  If the front grille of your Twin Eagles Patio Heater deteriorates, it could be because the tip angle exceeds 30 degrees, causing combustion products to vent out to the front grille instead of the top. Correct the installation to ensure only radiant heat passes through the front grille. Another cause could be windy conditions, so locate the heater in less windy conditions.

Summary

Safety Precautions for Gas Infrared Heaters

Procedure When Smelling Gas

If a gas smell is detected, open windows, avoid ignition sources, and immediately contact the gas supplier or fire department.

Fire Hazard Warning

Do not store or use flammable vapors or liquids near the heater to prevent death, injury, or property damage.

Asphyxia, Explosion, or Fire Hazard

Improper installation, adjustment, operation, or maintenance can create hazardous conditions.

Front Grille Blocking Warning

Never block the front grille of the heater; it is not suitable for hazardous locations.

Carbon Monoxide Warning

Improper use may expose users to carbon monoxide, which is hazardous to health.

Weather Conditions Warning

Heaters must be protected from rain, moisture, and high winds to ensure proper function.

Twin Eagles Gas Infrared Heater Features

Getting Started

Initial steps include inspecting packaging, verifying accessories, and reading the manual before installation.

Gas Installation Requirements

Code Requirements for Installation

Installation must comply with national and local fuel gas and electrical codes.

Gas Supply and Piping Specifications

Details on gas inlet pressure, pipe sizing, shut-off valve requirements, and sealant.

Qualified Technician for Gas Connections

Emphasizes that all gas connections must be performed by qualified and experienced technicians.

Leak Test Procedure

Pre-Test Cautions and Guidelines

Warnings against open flames for leak detection; advises checking hoses and propane tanks.

Performing the Leak Test

Step-by-step instructions for checking gas connections and hoses using a soapy water solution.

Selecting Mounting Location

Anchoring and Support Requirements

Ensures secure mounting to prevent suspension hazards and maintain stability.

Combustible Material Clearances

Specifies minimum distances from combustible materials to prevent fire hazards.

Weather Protection Needs

Highlights the need to protect the heater from environmental elements like rain and wind.

Fire Sprinkler System Proximity

Advises maintaining distance from fire sprinklers and avoiding flammable sprinkler fluids.

Ventilation and Airflow Requirements

Details on ensuring proper combustion air supply and exhaust of combustion gases.

Heating Area Coverage Guidelines

Information on effective heating area based on mounting height and environmental conditions.

Patio Design and Heater Placement

Critical factors for heater placement for optimal heating efficiency and comfort.

Mounting Bracket Assembly and Angles

Instructions on using manufacturer brackets and permissible mounting angles.

Gas Inlet Port Orientation

Specifies the correct side for the gas inlet to prevent damage and warranty voidance.

Mounting Angles and Clearances

Details on permissible mounting angles and required clearances for ventilation.

Mounting Clearances

Minimum Clearances to Combustibles

Specifies required distances from sides, back, above, and below the heater to combustible materials.

Electrical Instructions

Remote Control Battery Installation

Steps for inserting batteries into the wireless remote control for proper operation.

AC Adapter Installation

Guidelines for connecting an optional AC adapter for power supply and battery backup.

Operating Instructions

Initial Start-Up and Remote Synchronization

Procedures for initial heater setup, including remote control synchronization.

Pilot Burner Ignition Test

Steps to test the pilot burner's ignition and gas valve functionality.

Gas Leak Detection Procedure

Specific safety instructions for handling gas smells and what to do in an emergency.

Heater Operation Guide

Instructions on how to turn on the heater, select heat settings, and observe initial operation.

HI-LOW Heat Setting Adjustment

How to adjust the heater between high (37,000 BTU/Hr) and low (25,000 BTU/Hr) heat levels.

Heater Shutdown Procedure

Steps for safely turning off the heater and the main gas supply if needed.

Preventive Maintenance

Stainless Steel Surface Cleaning

Recommendations for cleaning the stainless steel housing to maintain its appearance.

Routine Leak Testing

Advice on performing leak tests seasonally and inspecting connections for corrosion.

Preventing Spider and Insect Infestation

Warning about insect nests in the burner and recommended annual inspection.

Electrical Safety Precautions

Safety warning regarding disconnecting power and grounding the heater before servicing.

Troubleshooting Guide

Important Troubleshooting Notes

Key observations and common occurrences during initial use and operation.

Limited Product Warranty

Residential Use Warranty Terms

Details the one-year warranty for residential applications, excluding normal wear.

Commercial Use Warranty Terms

Outlines the ninety-day warranty for commercial applications.

Warranty Exclusions and Limitations

Lists conditions and actions that void the warranty, such as improper installation or weather exposure.

Obtaining Warranty Service

Instructions on how to contact Twin Eagles for warranty service and required information.

Implied Warranty Limitations

Notes on state variations regarding the duration of implied warranties.

Twin Eagles TEGH48 Specifications

General

Brand	Twin Eagles
Model	TEGH48
Category	Patio Heater
Language	English
