twintex TP Series User Manual

- 2 -
3. SPECIFICATIONS
Table 1
Model TP-1303EC
TP-1303C
TP-1303
TP-1305EC
TP-1305C
TP-1305
TP-1603EC
TP-1603C
TP-1603
Constant voltage operation
Line regulation ≤0.01%+3mV ≤0.01%+3mV ≤0.01%+5mV
Load regulation
≤0.01%+3mV
≤0.02%+5mV
≤0.02%+5mV
Ripple & Noise ≤3mVrms, 5Hz~1MHz
Constant current operation
Line regulation ≤0.2%+3mA
Load regulation
≤0.2%+3mA
≤0.2%+5mA
≤0.2%+3mA
Fixed output (Only for TP-1303/1305/1603)
Output voltage
5V±1%
Output current 1A
Ripple & noise
≤3mVrms, 5Hz~1MHz
Display
Voltmeter
3 digits LED display
Ammeter 3 digits LED display
Resolution
100mV/10mA
Accuracy ±(1% reading+2 digits)
General
Operating environment 0℃~40℃, ≤80%RH
Storage environment
-10
℃
~70
℃
, ≤70%RH
Power source AC110V/220V±10%, 50/60Hz
Accessories
Power cord x1, Operation manual x1, Test lead x1
Dimension 130Wx160Hx310Dmm
