16. X Axis motor, Y Axis motor, Y End stop
X轴电机、Y轴电机、Y限位接线
Profile Cover Strip 型材封条 x 3
The wires goes and hidden inside the groove, then seal with 3 profile cover strips.
接线沿着型材往上，并隐藏在凹槽内，再用3个型材封条扣紧。
17. Connect the E-axis Motor Wire and Filament Sensor
连接E轴电机线和断料检测器
→
→
→
