20. About the Fan Wire and the X Axis End Stop
关于连接风扇线和X轴限位开关线
No.1 and No.2 wire are both fan wires. 1号和2号线都是风扇线。
They are connected according to the corresponding numbers. 根据对应的数字连接。
X-axis limit switch line is inserted into the X-axis limit switch line.
X轴限位转接线与X轴限位开关线对接。(X-axis is on the top carriage X轴在马车顶部上)
21. Seal the Wiring Cover 封上接线盖板
Hide the wires into the printer case. 把线束藏到打印机机箱里。
SP-5 20TWOTREES
