Tyco D3 PROTECTOSPRAY - Page 4

TFP802
Page 4 of 6
MAXIMUM AXIAL DISTANCE FOR 125° SPRAY ANGLE
IN FEET AND INCHES
FIXED
ANGLE
ORIFICE SIZE
16 18 21 24 28 32 34
0° 4-6 5-0 6-6 7-9 10-0 10-3 10-6
30° 3-9 3-9 6-3 6-9 8-6 8-6 8-9
45° 3-0 3-6 5-9 6-0 7-9 7-6 8-3
60° 2-6 3-0 5-6 5-9 7-3 7-3 7-9
90° 2-0 2-9 4-9 5-0 5-9 6-0 6-6
120° 1-9 2-3 3-3 3-3 3-9 3-9 4-6
135° 1-6 1-9 2-6 2-6 3-3 3-3 3-9
150° 1-6 1-6 2-0 2-3 2-6 2-9 3-6
180° 1-3 1-3 1-9 2-0 2-3 2-6 3-3
MAXIMUM AXIAL DISTANCE FOR 140° SPRAY ANGLE
IN FEET AND INCHES
FIXED
ANGLE
ORIFICE SIZE
16 18 21 24 28 32 34
0° 4-0 4-6 6-0 6-6 8-0 8-0 8-0
30° 3-3 3-6 5-6 5-6 6-3 7-0 7- 0
45° 2-9 2-9 5-0 5-0 5-6 6-6 6-6
60° 2-3 2-6 4-6 4-6 5-3 5-6 5-9
90° 1-9 2-3 4-0 4-0 4-6 4-6 5-0
120° 1-6 1-9 2-3 2-3 2-6 3-0 3-6
135° 1-3 1-6 1-6 1-6 2-0 2-6 2-9
150° 1-3 1-3 1-6 1-6 1-9 2-3 2-6
180° 1-0 1-0 1-3 1-3 1-6 2-0 2-3
MAXIMUM AXIAL DISTANCE FOR 160° SPRAY ANGLE
IN FEET AND INCHES
FIXED
ANGLE
ORIFICE SIZE
16 18 21 24 28 32 34
0° 3-6 3-9 4-9 5-0 6-0 6-9 7-0
30° 2-9 3-0 4-3 4-6 5-0 5-9 6-3
45° 2-3 2-6 3-9 4-0 4-6 5-3 5-6
60° 1-9 2-3 3-6 3-9 4-3 4-9 5-3
90° 1-3 1-9 3-0 3-3 3-6 3-9 4-3
120° 1-0 1-3 1-6 2-0 2-0 2-3 2-6
135° 1-0 1-0 1-3 1-3 1-6 1-9 2-0
150° 0-9 0-9 1-0 1-0 1-6 1-6 1-9
180° 0-9 0-9 0-9 0-9 1-3 1-6 1-6
MAXIMUM AXIAL DISTANCE FOR 180° SPRAY ANGLE
IN FEET AND INCHES
FIXED
ANGLE
ORIFICE SIZE
16 18 21 24 28 32 34
0° 2-9 3-0 3-6 3-6 4-0 6-0 6-0
30° 2-3 2-3 3-6 3-6 3-9 5-0 5-0
45° 1-9 2-0 3-3 3-3 3-6 4-3 4-3
60° 1-6 1-9 2-9 2-9 3-3 3-9 3-9
90° 1-0 1-6 2-0 2-0 2-6 3-0 3-0
120° 0-9 1-0 1-0 1-0 1-6 1-6 1-6
135° 0-6 0-9 0-9 0-9 1-3 1-3 1-3
150° 0-6 0-6 0-6 0-6 1-0 1-0 1-0
180° 0-6 0-6 0-6 0-6 0-9 0-9 0-9
MAXIMUM AXIAL DISTANCE FOR 65° SPRAY ANGLE
IN FEET AND INCHES
FIXED
ANGLE
ORIFICE SIZE
16 18 21 24 28 32 34
0° 10-6 12-6 13-0 13-3 14-6 15-0 15-6
30° 8-3 10-9 10-9 11-9 12-6 13-6 13-9
45° 7-3 10-0 10-0 11-3 11- 6 12-6 12-9
60° 6-6 9-3 9-6 10-9 11- 0 11-9 12-6
90° 6-0 8-6 9-0 10-3 10-6 10-9 11- 6
120° 5-9 7- 6 7-6 7-6 8-3 9-0 9-6
135° 5-3 6-0 6-3 6-6 7-0 8-0 8-6
150° 5-3 5-6 5-6 5-9 6-3 7-3 7-6
180° 5-0 5-0 5-0 5-6 5-9 6-6 7-0
MAXIMUM AXIAL DISTANCE FOR 80° SPRAY ANGLE
IN FEET AND INCHES
FIXED
ANGLE
ORIFICE SIZE
16 18 21 24 28 32 34
0° 9-0 10-6 11- 0 12-0 13-0 14- 0 14-0
30° 7-3 8-3 8-9 10-6 11- 6 12-3 12-3
45° 6-3 7-6 8-0 10-3 10-6 11- 3 11- 3
60° 5-6 7-0 7-6 10-0 10-3 10-9 10-9
90° 5-0 6-0 7-0 9-3 9-6 9-9 10-0
120° 4-6 4-9 5-9 6-6 7-3 7- 0 8-0
135° 4-3 4-6 5-0 5-6 6-0 6-3 6-9
150° 4-0 4-0 4-6 5-0 5-6 5-6 6-0
180° 3-9 3-9 4-0 4-6 4-9 5-3 5-6
MAXIMUM AXIAL DISTANCE FOR 95° SPRAY ANGLE
IN FEET AND INCHES
FIXED
ANGLE
ORIFICE SIZE
16 18 21 24 28 32 34
0° 7-0 7-9 9-6 10-6 11- 0 12-0 12-6
30° 5-9 6-6 7-9 9-9 10-6 10-9 11- 0
45° 5-3 6-3 7-0 9-6 9-9 10-3 10-3
60° 4-9 6-0 6-9 9-3 9-6 9-9 9-9
90° 4-0 5-0 6-6 8-3 8-6 8-9 8-9
120° 3-6 3-9 5-0 5-3 6-3 6-0 6-6
135° 3-3 3-6 4-0 4-6 5-3 5-3 5-6
150° 3-0 3-0 3-6 4-0 4-6 4-6 4-9
180° 3-0 3-0 3-3 3-9 4-0 4-3 4-6
MAXIMUM AXIAL DISTANCE FOR 110° SPRAY ANGLE
IN FEET AND INCHES
FIXED
ANGLE
ORIFICE SIZE
16 18 21 24 28 32 34
0° 6-0 7-0 9-0 9-6 11- 0 11- 3 11- 6
30° 5-3 6-3 7-3 8-9 9-6 9-9 10-0
45° 4-9 5-9 6-6 8-6 9-0 9-0 9-3
60° 4-3 5-6 6-3 8-3 8-6 8-6 8-9
90° 3-6 4-6 5-9 7- 6 7-6 7-6 7-9
120° 2-9 3-3 4-6 4-6 5-6 5-6 5-6
135° 2-6 2-9 3-6 3-6 4-6 4-6 4-9
150° 2-3 2-6 3-0 3-3 3-6 3-9 4-3
180° 2-3 2-3 2-9 3-0 3-3 3-6 3-9
TABLE C
MAXIMUM AXIAL DISTANCE BETWEEN NOZZLE TIP AND
PLANE-OF-PROTECTION FOR EXPOSURE PROTECTION — FEET AND INCHES
