28
Figure 12-2 Telephone Connection
RED (R)
GREEN (T)
GRAY (R)
BROWN (T)
RJ-31X
RING
TIP
CONTROL PANEL
Incoming
Phone line
Handset
RI
TI
T1
R1
TIP
RING
4
321
5
Communicator
TIP T1 R1
RING
Figure 12-3 Power Supply and Supervision Wiring Diagram
(BLK/WHT) +13.8VDC
(BLK ) GND
Control
Panel
EOL
Resistor
See Note 3
DSC
RM-2
RELAY
NC
C
NO
ZONE
TERMINALS
(See Note 1)
- +
+12VDC
GND
CONTROL PANEL
Aux Power
+ -
DSC
Supervision
Relay
See Note 2
17
16
151412
18
13
11
1097 86
19
Z4
Z3Z2
COM
20
Z1
AUX
+
PGM
3
PGM
1
PGM
4
COM
Communicator
PGM
3
DC IN
+ -
Power Adaptor
Notes:
1. Program the zone/point as “Supervisory” type with keypad-
only announciation when in alarm. Do NOT use a zone/point
that is normally used for 2-wire smoke detectors.
2. The power supervision relay (RM-2) is only used when the
3G4010/LE4010 is not powered by the control panel. The
relay is not required since a loss of input power will generate
a signal to the CMC.
3. Output 4 on the 3G4010/LE4010 must be set as “Active
High” (default).
4. This equipment has no mains on/off switch. The plug of the
direct plug-in power supply is intended to serve as the dis-
connecting method if the equipment must be quickly dis-
connected. Ensure that access to the mains plug and
associated mains socket/outlet is never obstructed.
3G4010/LE4010 Installation Manual
