INSTALLATION AND OPERATING INSTRUCTIONS
Page 2
SECTION 2: MOUNTING OF SAUNA HEATER
SECTION 3: PLACING OF ROCKS
Carefully locate the heater according to the dimensions shown in Diagram 1 and
bolt it to the oor. (Bolts are not supplied with the heater.) Tighten to secure the
heater in place.
The rocks supplied with the heater have been chosen to provide the best heater
performance. Use of any other type of rock may void the heaters warranty.
Never operate the heater without rocks in place! Rinse the rocks with water before
placing in the heater. Place the larger rocks between the elements and the
smallest rocks between the elements and the inner rock compartment of the
heater. Place the rocks loosely so the air can circulate. Continue adding rocks
until there is 1 layer above the heating elements. Packing the rocks too tightly
may cause the heater high limit switch to trip. Attach the rock guard with the
screws provided.
Fire sprinkler systems used
inside any sauna room should
be properly rated for sauna
room temperatures.
Do not pour chlorinated pool
or spa water on heater.
Excessive water use on heater
may cause damage and void
warranty.
Do not install a shower in
sauna room.
Electric Shock Hazard - High
voltage exists within this
equipment. There are no user
serviceable parts in this
equipment. All installation and
service to this equipment
should be performed by
qualied licensed personnel in
accordance with local and
national codes.
Do not construct sauna room
so as to restrict air ow
through the bottom of the
heater.
Packing the rocks too tightly
may cause the heater high
limit switch to trip.
SECTION 4: ELECTRICAL HOOK-UP
SECTION 6: HEATER SCREEN (GUARD RAIL)
Install a wooden heater guard to prevent the sauna bather from accidentally
touching the sauna heater. Install the heater guard rail with the height clearances
and dimensions shown in Diagram 1.
SECTION 5: TEMPERATURE SENSOR
Feed the "low voltage" sensor wire from the control to the sensor location. Senor
wire must be routed completely seperate (as per low voltage electrical wiring
codes) from any wiring carrying over 50 volts. It may be necessary to drill holes
to string the wire through the studs or ceiling joists. Route wires into control box
and connect to terminals #2 and #3 at the thermostat terminal block. Using a
at tip screwdriver, unsnap sensor cover from sensor as shown in Diagram 2.
Mount sensor horizontally to the nished wall directly above heater using two (2)
screws (provided) as shown in Diagrams 1 & 3.
Electrical installation must be made by a licensed electrician in accordance with
the National Electrical Code and local regulations.
This heater is intended for use with SC Controls only. Use of any other control
type will void the warranty and ETL listing. The control panel and contactor box
must be installed in a dry location outside the sauna room. The control panel
must be located to allow installation of the thermostat's temperature sensor
shown in Diagram 1. The sensor wire supplied is 9 feet, but it may be extended at
the control end with 2 conductor wire.
The model CB 7-3 contactor box is required for use with a three phase heater, the
model CB 7-1 contactor box is required for use with a single phase heater. To
determine the correct wire size, refer to Table 1. Use copper supply wire only,
suitable for minimum 90 degrees C. The heater must be grounded! See the
heater and control wiring diagrams for proper connections.
